服务发现

服务发现测试

在k8s集群中，组件之间可以通过定义的Service名称实现通信。

# 查看 service
$ kubectl -n test get svc
NAME        TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)        AGE
myblog      ClusterIP   10.104.58.9     <none>        80/TCP         12d
myblog-np   NodePort    10.98.222.213   <none>        80:31174/TCP   11d
mysql       ClusterIP   10.110.89.44    <none>        3306/TCP       11d

# 新建一个测试pod，因为只是测试，设置保持hang住即可
cat > testpod.yaml <<EOF
apiVersion: apps/v1
kind: Deployment
metadata:
  name: testpod
  namespace: test
spec:
  replicas: 1
  selector:
    matchLabels:
      app: testpod
  template:
    metadata:
      labels:
        app: testpod
    spec:
      containers:
        - name: testpod
          image: alpine:3.18.3
          imagePullPolicy: IfNotPresent
            command: ["/bin/sh"]
            args: ["-c", "while true; do echo hello; sleep 100;done"]
EOF

# 创建测试pod
$ kubectl -n test create -f testpod.yaml

# 进入测试pod
$ kubectl -n test exec -ti testpod-865855cfc5-m2f99 -- sh
/ # apk add curl
/ # curl http://myblog
/ # exit

可以发现，服务是可以直接通过service名称访问的。
虽然pod ip和cluster ip都不固定，但是service name是固定的，而且具有完全的跨集群可移植性，因此组件之间调用的同时，完全可以通过service name去通信，这样避免了大量的ip维护成本，使得服务的yaml模板更加简单。因此可以对mysql和myblog的部署进行优化改造。

blog 优化改造

mysql可以去掉hostNetwork部署，使得服务只暴漏在k8s集群内部网络
configMap中数据库地址可以换成Service名称，这样跨环境的时候，配置内容基本上可以保持不用变化

修改deploy-mysql.yaml，去掉hostNetwork和hostPort

apiVersion: apps/v1
kind: Deployment
metadata:
  name: mysql
  namespace: test
spec:
  # 指定Pod副本数
  replicas: 1
  # 指定Pod的选择器
  selector:
    matchLabels:
      app: mysql
  # 指定Pod的模板，与上一节定义的Pod模板类似
  template:
    metadata:
      labels:
        app: mysql
    spec:
      # 去掉此行
      # hostNetwork: true
      volumes:
        - name: mysql-data
          hostPath:
            path: /opt/mysql/data
      # 使用节点选择器将Pod调度到指定label的节点
      nodeSelector:
        component: mysql
      containers:
        - name: mysql
          image: mariadb:11.1
          args:
            - --character-set-server=utf8mb4
            - --collation-server=utf8mb4_unicode_ci
          ports:
            - containerPort: 3306
          env:
            - name: MYSQL_USER
              valueFrom:
                secretKeyRef:
                  name: myblog-secret
                  key: MYSQL_USER
            - name: MYSQL_ROOT_PASSWORD
              valueFrom:
                secretKeyRef:
                  name: myblog-secret
                  key: MYSQL_PASSWD
            - name: MYSQL_DATABASE
              valueFrom:
                configMapKeyRef:
                  name: myblog
                  key: MYSQL_DATABASE
          volumeMounts:
            - name: mysql-data
              mountPath: /var/lib/mysql

修改configmap.yaml

apiVersion: v1
kind: ConfigMap
metadata:
  name: myblog
  namespace: test
data:
  # 此处替换为mysal
  MYSQL_HOST: "mysql"
  MYSQL_DATABASE: "myblog"
  MYSQL_PORT: "3306"

应用修改：

# 更新configmap
$ kubectl -n test delete -f configmap.yaml
$ kubectl -n test create -f configmap.yaml

# 更新mysql
$ kubeclt -n test delete -f deploy-mysql.yaml
$ kubeclt -n test create -f deploy-mysql.yaml

服务发现组件

在k8s中，服务发现组件使用的是 CoreDNS，组件之间可以通过定义的Service名称实现通信。组件效率非常高，可以达到每秒几万次的解析速度，并且对应用没有任何侵入性，对应用来说，只需要通过service name就可以实现服务发现。
CoreDNS是一个Go语言实现的链式插件DNS服务端，是CNCF成员，是一个高性能、易扩展的DNS服务端。

# 进入 test pod
$ kubectl -n test exec -it  testpod-865855cfc5-m2f99 -- sh
/ # cat /etc/resolv.conf
search test.svc.cluster.local svc.cluster.local cluster.local iluvatar.local
nameserver 10.96.0.10
options ndots:5
/ #

# 可以看到域名解析的nameserver是10.96.0.10，这个地址是kube-dns的service地址，具体怎么找到对应的pod呢？

# 查看所有的service
$ kubectl -n kube-system get svc -A
NAMESPACE     NAME         TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)                  AGE
default       kubernetes   ClusterIP   10.96.0.1       <none>        443/TCP                  24d
kube-system   kube-dns     ClusterIP   10.96.0.10      <none>        53/UDP,53/TCP,9153/TCP   24d
test          myblog       ClusterIP   10.104.58.9     <none>        80/TCP                   12d
test          myblog-np    NodePort    10.98.222.213   <none>        80:31174/TCP             11d
test          mysql        ClusterIP   10.110.89.44    <none>        3306/TCP                 11d

# 可以看到10.96.0.10这个ip出现在了kube-system这个命名空间，而且是kube-dns这个service的cluster-ip地址，这个地址是固定的，不会变化，因此可以在pod中直接写死这个地址，而不用担心变化的问题。

# 查看对应svc的selector信息
$ kubectl -n kube-system get svc -o wide
NAME       TYPE        CLUSTER-IP   EXTERNAL-IP   PORT(S)                  AGE   SELECTOR
kube-dns   ClusterIP   10.96.0.10   <none>        53/UDP,53/TCP,9153/TCP   24d   k8s-app=kube-dns

# 根据selector信息，查看对应的pod
$ kubectl -n kube-system get po -o wide -l k8s-app=kube-dns
NAME                       READY   STATUS    RESTARTS   AGE   IP           NODE        NOMINATED NODE   READINESS GATES
coredns-66f779496c-cx2zv   1/1     Running   0          24d   10.244.1.2   k8s-node1   <none>           <none>
coredns-66f779496c-t5zs2   1/1     Running   0          24d   10.244.1.3   k8s-node1   <none>           <none>

# 可以看到coredns是通过deployment部署的，而且有两个pod，这样可以保证高可用，同时也可以提高解析效率。

## 启动pod的时候，会把kube-dns服务的cluster-ip地址注入到pod的resolve解析配置中，同时添加对应的namespace的search域。 因此跨namespace通过service name访问的话，需要添加对应的namespace名称，
service_name.namespace
$ kubectl get svc
NAME         TYPE        CLUSTER-IP   EXTERNAL-IP   PORT(S)   AGE
kubernetes   ClusterIP   10.96.0.1    <none>        443/TCP   26h

扩展：怎么访问其他集群的服务？

# 在default命名空间下创建一个pod作为测试pod
$ cat > deploy-mynginx.yaml <<EOF
apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx
spec:
  replicas: 1
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      containers:
        - name: nginx
          image: nginx:1.25
          imagePullPolicy: IfNotPresent
          ports:
            - containerPort: 80
---
apiVersion: v1
kind: Service
metadata:
  name: nginx
spec:
  ports:
  - port: 80
    protocol: TCP
    targetPort: 80
  selector:
    app: nginx
  type: ClusterIP

EOF

$ kubectl create -f deploy-mynginx.yaml
$ kubectl get po
NAME                    READY   STATUS    RESTARTS   AGE
nginx-cd5968d5b-66mns   1/1     Running   0          25s
$ kubectl get svc
NAME         TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)   AGE
kubernetes   ClusterIP   10.96.0.1       <none>        443/TCP   24d
nginx        ClusterIP   10.105.117.66   <none>        80/TCP    30s

# 直接在主机访问可以访问到
$  curl http://10.105.117.66
<!DOCTYPE html>
<html>
<head>
<title>Welcome to nginx!</title>
<style>
html { color-scheme: light dark; }
body { width: 35em; margin: 0 auto;
font-family: Tahoma, Verdana, Arial, sans-serif; }
</style>
</head>
<body>
<h1>Welcome to nginx!</h1>
<p>If you see this page, the nginx web server is successfully installed and
working. Further configuration is required.</p>

<p>For online documentation and support please refer to
<a href="http://nginx.org/">nginx.org</a>.<br/>
Commercial support is available at
<a href="http://nginx.com/">nginx.com</a>.</p>

<p><em>Thank you for using nginx.</em></p>
</body>
</html>

进入test po进行访问
$ kubectl -n test exec -it  testpod-865855cfc5-m2f99 -- sh
/ # curl http://nginx
curl: (6) Could not resolve host: nginx

进入容器中访问会发现不行了，这是为什么呢？

这是因为这两个pod不在同一个命名空间，因此需要添加对应的命名空间名称，才能访问到。

之前查看test pod的resolve配置，可以看到有一个search域，这个域名就是test这个命名空间，因此可以直接访问test命名空间下的服务。

test pod中的resolve配置如下：

search test.svc.cluster.local svc.cluster.local cluster.local iluvatar.local
nameserver 10.96.0.10
options ndots:5

pod访问的时候会根据search域名进行解析，比如我们访问nginx

首先会尝试访问nginx.test.svc.cluster.local
如果访问不到，会尝试访问nginx.svc.cluster.local
如果访问不到，会尝试访问nginx.cluster.local
如果访问不到，会尝试访问nginx.iluvatar.local
如果访问不到，会尝试访问nginx
如果访问不到，会报错

这是pod访问的时候的解析流程。
为什么能访问到test命名空间下的服务呢？就是因为第一个域名解析成功了，因此后面的域名就不会再解析了。第一个域名包含着命名空间信息。
那我们直接使用全域名能访问吗？

# 直接使用全域名访问
$ kubectl -n test exec -it  testpod-865855cfc5-m2f99 -- sh
/ # curl http://nginx.default.svc.cluster.local
<!DOCTYPE html>
<html>
<head>
<title>Welcome to nginx!</title>
<style>
html { color-scheme: light dark; }
body { width: 35em; margin: 0 auto;
font-family: Tahoma, Verdana, Arial, sans-serif; }
</style>
</head>
<body>
<h1>Welcome to nginx!</h1>
<p>If you see this page, the nginx web server is successfully installed and
working. Further configuration is required.</p>

<p>For online documentation and support please refer to
<a href="http://nginx.org/">nginx.org</a>.<br/>
Commercial support is available at
<a href="http://nginx.com/">nginx.com</a>.</p>

<p><em>Thank you for using nginx.</em></p>
</body>
</html>

所以使用全域名也是可以访问的。

那么有没有简便方法直接访问呢？有，就是添加一个namespace就行了，不需要全域名。

$ kubectl -n test exec -it  testpod-865855cfc5-m2f99 -- sh
/ # curl http://nginx.default
<!DOCTYPE html>
<html>
<head>
<title>Welcome to nginx!</title>
<style>
html { color-scheme: light dark; }
body { width: 35em; margin: 0 auto;
font-family: Tahoma, Verdana, Arial, sans-serif; }
</style>
</head>
<body>
<h1>Welcome to nginx!</h1>
<p>If you see this page, the nginx web server is successfully installed and
working. Further configuration is required.</p>

<p>For online documentation and support please refer to
<a href="http://nginx.org/">nginx.org</a>.<br/>
Commercial support is available at
<a href="http://nginx.com/">nginx.com</a>.</p>

<p><em>Thank you for using nginx.</em></p>
</body>
</html>

为什么这样也能访问呢？我们来撸一撸search的过程。

首先会尝试访问nginx.default.test.svc.cluster.local，此时会发现访问不到
然后会尝试访问nginx.default.svc.cluster.local，此时会发现这不就是全域名么，于是就访问成功了。

服务访问之Ingress

ingress 介绍

对于Kubernetes的Service，无论是Cluster-Ip还是NodePort均是四层的负载，集群内的服务如何实现七层的负载均衡，这就需要借助于Ingress，Ingress控制器的实现方式有很多，比如nginx, Contour, Haproxy, trafik, Istio。几种常用的ingress功能对比和选型可以参考这里
Ingress-nginx是7层的负载均衡器，负责统一管理外部对k8s cluster中Service的请求。主要包含：

ingress-nginx-controller：根据用户编写的ingress规则（创建的ingress的yaml文件），动态的去更改nginx服务的配置文件，并且reload重载使其生效（是自动化的，通过lua脚本来实现）；
Ingress资源对象：将Nginx的配置抽象成一个Ingress对象

比如下面这种配置：

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
name: ingress-wildcard-host
spec:
rules:
- host: "foo.bar.com"
  http:
    paths:
    - pathType: Prefix
      path: "/bar"
      backend:
        service:
          name: service1
          port:
          number: 80
- host: "bar.foo.com"
  http:
    paths:
    - pathType: Prefix
      path: "/foo"
      backend:
        service:
          name: service2
          port:
            number: 80

对应示意图如下：

实现逻辑

ingress controller通过和kubernetes api交互，动态的去感知集群中ingress规则变化
然后读取ingress规则(规则就是写明了哪个域名对应哪个service)，按照自定义的规则，生成一段nginx配置
再写到nginx-ingress-controller的pod里，这个Ingress controller的pod里运行着一个Nginx服务，控制器把生成的nginx配置写入/etc/nginx/nginx.conf文件中
然后reload一下使配置生效。以此达到域名分别配置和动态更新的问题。

ingress安装

# 注意：这里的逻辑会随着时间推移变老，如果是新集群，建议参考官方文档 https://kubernetes.github.io/ingress-nginx/deploy/#quick-start
$ wget https://raw.githubusercontent.com/kubernetes/ingress-nginx/controller-v1.9.4/deploy/static/provider/cloud/deploy.yaml

## 修改部署节点
$ vim deploy.yaml

apiVersion: apps/v1
kind: Deployment
metadata:
  labels:
    app.kubernetes.io/component: controller
    app.kubernetes.io/instance: ingress-nginx
    app.kubernetes.io/name: ingress-nginx
    app.kubernetes.io/part-of: ingress-nginx
    app.kubernetes.io/version: 1.9.4
  name: ingress-nginx-controller
  namespace: ingress-nginx
spec:
  minReadySeconds: 0
  ......
  dnsPolicy: ClusterFirst
  nodeSelector:
    kubernetes.io/os: linux
    # 添加这一行，只有对应label的节点才会部署ingress-nginx
    ingress: true
  # 添加这一行，使得ingress-nginx可以访问到宿主机的网络
  hostNetwork: true
  serviceAccountName: ingress-nginx
  terminationGracePeriodSeconds: 300
  ......

创建ingress

# 为k8s-master节点添加label
$ kubectl label node k8s-master ingress=true
$ kubectl apply -f deploy.yaml

ingress使用

创建资源

编写文件 myblog/deployment/ingress.yaml：

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: myblog
  namespace: test
spec:
  ingressClassName: nginx
  rules:
  - host: myblog.test.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: myblog
            port:
              number: 80

ingress-nginx动态生成upstream配置：

$ kubectl -n ingress-nginx exec -ti ingress-nginx-controller-67f74f8554-scwtp -- sh
# ps aux
# cat /etc/nginx/nginx.conf|grep myblog -A10 -B1
...
        ## start server myblog.test.com
        server {
                server_name myblog.test.com ;

                listen 80  ;
                listen [::]:80  ;
                listen 443  ssl http2 ;
                listen [::]:443  ssl http2 ;

                set $proxy_upstream_name "-";

                ssl_certificate_by_lua_block {
                        certificate.call()
                }

                location / {

                        set $namespace      "test";
                        set $ingress_name   "myblog";
                        set $service_name   "myblog";
                        set $service_port   "80";
                        set $location_path  "/";

                        rewrite_by_lua_block {
                                lua_ingress.rewrite({
                                        force_ssl_redirect = false,
                                        ssl_redirect = true,
                                        force_no_ssl_redirect = false,
                                        use_port_in_redirects = false,
                                })
--
                                balancer.log()

                                monitor.call()

                                plugins.run()
                        }

                        port_in_redirect off;

                        set $balancer_ewma_score -1;
                        set $proxy_upstream_name "test-myblog-80";
                        set $proxy_host          $proxy_upstream_name;
                        set $pass_access_scheme  $scheme;

                        set $pass_server_port    $server_port;

                        set $best_http_host      $http_host;
                        set $pass_port           $pass_server_port;

                        set $proxy_alternative_upstream_name "";

--
                        proxy_next_upstream_timeout             0;
                        proxy_next_upstream_tries               3;

                        proxy_pass http://upstream_balancer;

                        proxy_redirect                          off;

                }

        }
        ## end server myblog.test.com

访问

域名解析服务，将 myblog.test.com解析到ingress的地址上。ingress是支持多副本的，高可用的情况下，生产的配置是使用lb服务（内网F5设备，公网elb、slb、clb，解析到各ingress的机器，如何域名指向lb地址）

本机，添加如下hosts记录来演示效果。

192.168.100.2 myblog.test.com

然后，访问 http://myblog.test.com/
HTTPS访问：

#自签名证书
$ openssl req -x509 -nodes -days 2920 -newkey rsa:2048 -keyout tls.key -out tls.crt -subj "/CN=*.test.com/O=ingress-nginx"

# 证书信息保存到secret对象中，ingress-nginx会读取secret对象解析出证书加载到nginx配置中
$ kubectl -n test create secret tls tls-myblog --key tls.key --cert tls.crt

修改yaml

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: myblog
  namespace: test
spec:
  rules:
  - host: myblog.test.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: myblog
            port:
              number: 80
  tls:
  - hosts:
    - myblog.test.com
    secretName: tls-myblog

然后，访问 https://myblog.test.com/

常用注解说明

nginx端存在很多可配置的参数，通常这些参数在ingress的定义中被放在annotations中实现，如下为常用的一些：

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: myblog
  namespace: test
  annotations:
    nginx.ingress.kubernetes.io/force-ssl-redirect: "false"
    nginx.ingress.kubernetes.io/proxy-body-size: 1000m
    nginx.ingress.kubernetes.io/ssl-redirect: "false"
    nginx.org/client-max-body-size: 1000m
spec:
  rules:
  - host: myblog.test.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: myblog
            port:
              number: 80
  tls:
  - hosts:
    - myblog.test.com
    secretName: tls-myblog

nginx.ingress.kubernetes.io/force-ssl-redirect: “false”：是否强制重定向到https
nginx.ingress.kubernetes.io/proxy-body-size: 1000m：设置请求体的最大值
nginx.ingress.kubernetes.io/ssl-redirect: “false”：是否重定向到https
nginx.org/client-max-body-size: 1000m：设置请求体的最大值
nginx.ingress.kubernetes.io/proxy-buffering: “on”：是否开启缓冲区
nginx.ingress.kubernetes.io/proxy-buffer-size: 1000m：设置缓冲区大小
nginx.ingress.kubernetes.io/proxy-buffers-number: 1000m：设置缓冲区数量
nginx.ingress.kubernetes.io/proxy-connect-timeout: 1000m：设置连接超时时间
nginx.ingress.kubernetes.io/proxy-read-timeout: 1000m：设置读取超时时间
nginx.ingress.kubernetes.io/proxy-send-timeout: 1000m：设置发送超时时间
nginx.ingress.kubernetes.io/proxy-max-temp-file-size: 1000m：设置临时文件大小
nginx.ingress.kubernetes.io/proxy-request-buffering: “on”：是否开启请求缓冲区
nginx.ingress.kubernetes.io/rewrite-target: /$1：重写url
nginx.ingress.kubernetes.io/use-regex: “true”：是否使用正则表达式

多路径转发及重写的实现

多path转发示例

目标：

bookstore.test.com -> 192.168.100.3 -> /reviews   -> reviews service
                                       /details   -> details service

实现：

$ cat detail.dpl.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: details
  labels:
    app: details
spec:
  replicas: 1
  selector:
    matchLabels:
      app: details
  template:
    metadata:
      labels:
        app: details
    spec:
      containers:
        - name: details
          image: docker.io/istio/examples-bookinfo-details-v1:1.16.2
          imagePullPolicy: IfNotPresent
          ports:
            - containerPort: 9080

$ cat detail.svc.yaml
apiVersion: v1
kind: Service
metadata:
  name: details
  labels:
    app: details
spec:
  ports:
    - port: 9080
      name: http
  selector:
    app: details

# reviews.dpl.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: reviews
  labels:
    app: reviews
spec:
  replicas: 1
  selector:
    matchLabels:
      app: reviews
  template:
    metadata:
      labels:
        app: reviews
    spec:
      containers:
      - name: reviews
        image: docker.io/istio/examples-bookinfo-reviews-v3:1.16.2
        imagePullPolicy: IfNotPresent
        env:
        - name: LOG_DIR
          value: "/tmp/logs"
        ports:
        - containerPort: 9080

$ cat reviews.svc.yaml
apiVersion: v1
kind: Service
metadata:
  name: reviews
  labels:
    app: reviews
spec:
  ports:
  - port: 9080
    name: http
  selector:
    app: reviews

准备Ingress文件

# bookstore.ingress.yaml
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: bookstore
  namespace: default
spec:
  rules:
  - host: bookstore.test.com
    http:
      paths:
      - path: /reviews
        pathType: Prefix
        backend:
          service:
            name: reviews
            port:
              number: 9080
      - path: /details
        pathType: Prefix
        backend:
          service:
            name: details
            port:
              number: 9080

URL重写

目标：

bookstore.test.com -> 192.168.100.3 -> /api/reviews -> /reviews -> reviews service
                                       /details     -> /details -> details service

实现：

$ cat bookstore.reviews.ingress.yaml
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: bookstore-reviews
  namespace: default
  annotations:
    nginx.ingress.kubernetes.io/rewrite-target: /reviews/$1
spec:
  rules:
  - host: bookstore.test.com
    http:
      paths:
      - path: /api/reviews/(.*)
        pathType: Prefix
        backend:
          service:
            name: reviews
            port:
              number: 9080

$ cat bookstore.details.ingress.yaml
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: bookstore-details
  namespace: default
spec:
  rules:
  - host: bookstore.test.com
    http:
      paths:
      - path: /details
        pathType: Prefix
        backend:
          service:
            name: details
            port:
              number: 9080
